Weight dimensions
Width:440 mmDepth:350 mmHeight:44 mmWeight:4.66 kg
Power
AC input frequency:50 - 60 HzPower consumption max:471.67 WHeat dissipation:1609.41 BTU/hAC input voltage:100 - 240 V
Ports interfaces
Basic switching RJ-45 Ethernet ports type:Gigabit Ethernet (10/100/1000)SFP module slots quantity:4Power connector:AC-in jackBasic switching RJ-45 Ethernet ports quantity:24Fiber optic connector:SFP+USB 2.0 ports quantity:1
Network
Quality of Service QoS support:YNetworking standards:IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3at,IEEE 802.3az,IEEE 802.3xJumbo frames support:YPort mirroring:YLink aggregation:YBroadcast storm control:YSpanning tree protocol:YHead-of-line HOL blocking:Y10G support:YVLAN support:YCopper ethernet cabling technology:10BASE-T,10GBASE-T,100BASE-TX,1000BASE-TVirtual LAN features:Private VLAN,Voice VLAN,Tagged VLAN,MAC address-based VLAN,Port-based VLAN
Security
Access Control List ACL:YAuthentication:Guest VLAN, MAC-based authentication, Port-based authenticationAccess Control List ACL egress:512Root protection:YAccess Control List ACL ingress:2048IGMP snooping:YQueue scheduling algorithms:SP, WRR+SP, Weighted Round Robin (WRR)SSHSSL support:YLoop protection:YDHCP features:DHCP server,DHCP snooping,DHCP relay,DHCP clientBPDU filteringprotection:YDoS attack prevention:Y
Data transmission
Switching capacity:168 Gbit/sForwarding rate:125 MppsMAC address table:16384 entriesNumber of queues:8Packet buffer memory:2 MB
Endurance
Mean time between failures MTBF:409054 h
Management features
Switch type:ManagedSwitch layer:L3Web-based management:YARP inspection:YSystem event log:YMIB support:RFC 1213; RFC 4188; RFC 1157, 2571-2576; RFC 1907; RFC 1757, 2819; RFC 2021; RFC 1398, 1643, 1650, 2358, 2665; RFC 2674 802.1p 2233, 2863 IF MIB; RFC 2618; RFC 2620; RFC 2925; RFC 2674, 4363; RFC 1065, 1066, 1155, 1156, 2578; RFC 1215; RFC 1212; RFC 1215; RFC 1157, 2571-2576; RFC 4022; RFC 4113; RFC 4293; RFC 2737
Protocols
Virtual Router Redundancy Protocol VRRP:YRouting protocols:RIPGARP VLAN Registration Protocol GVRP:Y
Other features
Noise level:53.4 dBRedundant power supply RPS support:YNumber of VLANs:4000Flow control support:Y
Power over Ethernet PoE
Power over Ethernet PoE:YPower over Ethernet plus PoE ports quantity:24Total Power over Ethernet PoE budget:370 W
Packaging data
Package height:118 mmPackage weight:6.32 kgPackage width:450 mmPackage depth:595 mm
Operational conditions
Storage relative humidity H-H:5 - 90%Operating temperature T-T:0 - 50 °CStorage temperature T-T:-40 - 70 °COperating relative humidity H-H:10 - 90%
Design
Product colour:Black, GreyStackable:YLED indicators:YNumber of fans:3 fan(s)
Performance
Physical stacking units:9Virtual stacking units:32Telnet:YsFlow:Y
Logistics data
Pallet width:120 cmPallet length:110 cmShipping inner case length:46.8 cmShipping inner case net weight:19.5 kgQuantity per shipping inner case:3 pc(s)Shipping inner case height:62.6 cmShipping inner case width:37.4 cmPallet height air:2.01 mPallet gross weight sea:399.8 kgShipping inner case gross weight:21.2 kgNumber of cartons per pallet sea:18Pallet gross weight air:399.8 kgQuantity per pallet sea:54 pc(s)Number of cartons per pallet air:18Pallet height sea:2.01 mQuantity per pallet air:54 pc(s)
Certificates
Certification:FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC
Multicast features
Multicast support:YMulticast features:Controllable multicast
Features
Safety:CB, cUL, BSMI, CCCPassword protection:YSecurity algorithms:SNMP,SNMPv3,SSH-2,SSL/TLS
